16 Potentiometers And 16 Servos

What is the best way to hook up 16 servos to 16 10k potentiometers. It seems that the joy stick modual only allows 4 servos to 2 xy joysticks. I want use every aspect of a advanced joystick like yaw and different rotations. Maybe something seitek controller. Or make my own.

X52 controller

AI Support Bot
Related Content
Synthiam
Based on your post activity, we found some content that may be interesting to you. Explore these other tutorials and community conversations.
PRO
Synthiam
#1
I wouldn't connect analog pot's as joysticks to the EZ-B, that would defeat the purpose of wireless control.

I would connect the joystick to the computer and use the ARC Joystick Control. Since the maximum analog pots that DX Windows will support is 6, that limits you to 3 analog sticks.

You can connect more than one joystick to the computer.

Or, if you wish to switch the joystick between servo groups - look at the Example Project (Examples -> EZ Script ->Joystick Switch Between Servos)
#2
DIY Mech?

Dear DJ,
I have four servos working with four Pots though using USB joystick guts. Also DJ, I have 8 pots working using windows 7. The come up as throttle and yaw and other stuff like that. I also have an additional 16 buttons added and the EZ B detects them and seem to be OK(I have programmed them all to say something).

I know it has got to be possible. I also have a Steel Battalion controller (different project) I'm going to be testing and posting a video on this week or today some time. I ultimately want to make a suit using pots and my Makerbot 3D printer (custom parts for joint to potentiometers) that send singles to servos on a robot with about 16-20 pots. I plan on posting all of my findings here on EZ-Robot. Once I do that I then want to group function like you did in one of your videos and program them to this controller I have had sitting around since 2004. http://www.steelbattalion.org/controller.php .

Essentially, I want to use the post to record my physical potions and experiment with different poses. Then program them to buttons. Once I have done that I'm going to use my CNC machine and make a cool light weight body. Maybe even make some glass molds as a project with my daughter of the bot once I'm done.
